Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor
Module 1/3 Sensor

Information

Technical Specifications

  • Rated voltage: 100-240V~;
  • Self-consumption: <1W;
  • Operating frequency: 50/60Hz;
  • Surge protection: 1KV;
  • Coverage area: 120° with a reach of up to 7m in diameter and an ambient temperature of 25°C, at a height of approximately 1.2m;
  • Electrical connection: Wire connector from 0.5mm² to 2.5mm² (wires not included);
  • Note: This product features microprocessor technology and can be configured via the Smart X-Control app;
  • Time settings: 1 and 30 seconds, 1, 3, 5, 10, 15, 20, 25, 30 and 45 minutes, and 1, 2, 3 and 4 hours;
  • Light Sensor (LUX-PHOTOCELL): MIN (at night), MAX (dusk) and OFF (without photocell);
  • Sensitivity adjustment: 1 (sudden movements) to 3 (greater range);
  • Relay Function: The sensor functions as a timed photocontrolled relay. At dusk, it keeps the load switched on for the programmed time (0:30 to 12 hours) and then returns to sensor function.
  • Reset function: Returns the product settings to factory defaults;
  • Exclusive Inrush Control Technology, a near-zero network switching system (sine wave) that increases the lifespan of the load assembly (lamps, ballast, and sensor);
  • It has a GREEN LED indicator for operation and detection – when the product is operating in Relay Function mode, the LED oscillates (blinks slowly and gradually);
  • It has a RED LED to confirm successful recording of the configured parameters;
  • The sensor saves the previously configured parameters (timer settings, brightness, sensitivity, and operating mode) in case of power failure and restoration;
  • The maximum drive power should not be added together in parallel installations;
  • Energy savings of up to 75%;
  • Components: plastics, electronics, and metal alloys;
  • Factory settings: Time: 03 minutes, Photocell: OFF – Disabled and Sensitivity: Maximum;
  • Protection rating: IP32;
  • Warranty: 2 years;
  • Dimensions (LxWxH): 44.66×47.45×20.50mm;
  • Command Power:
FoodElectronics/LED/Halogen
220V220W
127V120W
THD<20% and FP>0.90

1/3 Module Wall Mount Presence Sensor Bivolt 120° Smart X-Control

available

Code: LEMOSP4006XC2

Description

The Smart X-Control 1/3 Wall Presence Sensor Module (LEMOSP006XC2) is an intelligent solution for timed load control. Equipped with an infrared sensor, the device detects movement from heat sources, such as people and vehicles, activating and keeping the load switched on as long as presence is detected. After the last detection, it automatically switches off after the programmed time.

Compatible with all sets and modules in Exatron's MyX electrical line, it guarantees versatility and seamless integration in various installations.

It features Smart X-Control technology, which allows you to configure the sensor directly from your smartphone, without needing to open the device or expose it to electricity. The Smart X-Control app is available for iOS and Android devices, offering convenience and security during setup.

Optimize your environment with cutting-edge technology and security with the Smart X-Control 1/3 Wall Mount Presence Sensor Module.

Download

User manual

R$ 40,43

Shipped within 7 business days.
Price* for end consumer

Information

Technical Specifications

  • Rated voltage: 100-240V~;
  • Self-consumption: <1W;
  • Operating frequency: 50/60Hz;
  • Surge protection: 1KV;
  • Coverage area: 120° with a reach of up to 7m in diameter and an ambient temperature of 25°C, at a height of approximately 1.2m;
  • Electrical connection: Wire connector from 0.5mm² to 2.5mm² (wires not included);
  • Note: This product features microprocessor technology and can be configured via the Smart X-Control app;
  • Time settings: 1 and 30 seconds, 1, 3, 5, 10, 15, 20, 25, 30 and 45 minutes, and 1, 2, 3 and 4 hours;
  • Light Sensor (LUX-PHOTOCELL): MIN (at night), MAX (dusk) and OFF (without photocell);
  • Sensitivity adjustment: 1 (sudden movements) to 3 (greater range);
  • Relay Function: The sensor functions as a timed photocontrolled relay. At dusk, it keeps the load switched on for the programmed time (0:30 to 12 hours) and then returns to sensor function.
  • Reset function: Returns the product settings to factory defaults;
  • Exclusive Inrush Control Technology, a near-zero network switching system (sine wave) that increases the lifespan of the load assembly (lamps, ballast, and sensor);
  • It has a GREEN LED indicator for operation and detection – when the product is operating in Relay Function mode, the LED oscillates (blinks slowly and gradually);
  • It has a RED LED to confirm successful recording of the configured parameters;
  • The sensor saves the previously configured parameters (timer settings, brightness, sensitivity, and operating mode) in case of power failure and restoration;
  • The maximum drive power should not be added together in parallel installations;
  • Energy savings of up to 75%;
  • Components: plastics, electronics, and metal alloys;
  • Factory settings: Time: 03 minutes, Photocell: OFF – Disabled and Sensitivity: Maximum;
  • Protection rating: IP32;
  • Warranty: 2 years;
  • Dimensions (LxWxH): 44.66×47.45×20.50mm;
  • Command Power:
FoodElectronics/LED/Halogen
220V220W
127V120W
THD<20% and FP>0.90
