Technical Specifications

• Voltage: 100-240V;
• Operating frequency: 50/60Hz;
• Power consumption: <0.4 W;
• Operating temperature: -5°C to +40°C;
• This product features microprocessor technology and comes pre-configured from the factory. Its functions can be altered using Smart X-Control technology, configured via the Smart X-Control app.
• Insensitive to sudden changes in brightness (headlights, lightning, laser pointers, etc.);
• Timer function: Automatic, 1, 1:30, 2, 2:30, 3, 3:30, 4, 4:30, 5, 5:30, 6, 6:30, 7, 7:30, 8, 8:30, 9, 9:30, 10, 10:30, 11, 11:30, 12 hours;
• Automatic function (AUTO): turns the light on when it gets dark and turns it off automatically when there is natural light;
• Photocell setting: 1 (at night) to 3 (at dusk);
• Random function: turns the light on and off randomly in the absence of natural light, varying between 10 minutes and 3 hours and 40 minutes;
• Lamp-friendly: load activation system with low electrical voltage <50V, increasing the lifespan of the assembly (lamps, ballast and sensor);
• Exclusive intelligent light learning system: prevents the flickering effect;
• Composition: plastic components, electronic components and metal alloys;
• Protection rating: IP30;
• Warranty: 2 years;
• Dimensions: Ø50x82mm;
• Control power:
